Mettler Toledo Safeline X33 Series food inspection equipment

Designed for small and medium sized packaging for single and multi-lane applications

Ensuring Food Safety

Designed for ease-of-use, the X33 offers high detection capabilities, safeguarding brands and consumers, while its low energy consumption reduces the total cost of ownership.

Software Facilitates Operator Control

Proprietary software enables operators to effortlessly program semi-automated product set-ups with minimal training required, ensuring uptime.

Maximizes Production Space Efficiency

Available at 800 or 1800mm system lengths, the X33 requires less line space to accommodate production planning constraints wherein space is a premium.

Sustainable Low Energy Solution

Powered by a 20W generator, the X33 is a low energy inspection solution delivering reduced Total Cost of Ownership.

Mettler Toledo – Al Thika Packaging LLC

Al Thika Packaging is the main distributor of Mettler Toledo in Middle East. Since 1994  Al Thika has been supplying a wide range of machinery including Garvens dynamic Checkweighing systemsSafeline X-ray inspection, Safeline integrated metal detection systems and CI-Vision inspection systems in Dubai, Abu Dhabi, Sharjah, Fujairah, Ras Al Khaimah, Ajman, Umm Al Quwain, Al Ain – UAE, Saudi Arabia, Bahrain, Oman and the many other Gulf countries.

Overview
Specifications – X33 Series
Conveyor Speed10 – 60 m/min (dependent on product dimensions)
Lane ConfigurationsSingle lane
Throughput RateUp to 300 ppm
Cooling MethodPassive fan assisted cooling
Screen Display10.1” LED display (16:9 aspect ratio)
Operating Temperature5 °C – 40 °C
Power Supply208 – 240 Vac, 1 phase, 50-60 Hz, 6 A max; 100 – 120 Vac, 1 phase, 50-60 Hz, 10 A max
Pneumatic Supply6 Bar(g) air supply required for reject system
X-ray Detector300mm or 400mm – 0.8mm diode size
X-ray Generator20W, 84kV, 0.25mA Glass or optional Beryllium Tube
X-ray BeamsSingle Beam
X-ray Emissions< 1uSv/hr
Reject TypePusher or airblast options
Material Number(s)30468718
Documentation

X-33 Inspection data sheet download.

x33_series_datasheet x-ray inspection

Cooling Solution Saves Operational Costs

An internal fan instead of an external air conditioning unit cools the X33, reducing maintenance time and Total Cost of Ownership.

Proves Due Diligence

All inspection activities are monitored and recorded in real-time to avoid product recalls and, if needed, demonstrate due diligence.

Optimum Detection at Reduced Power

The X33 uses the only 1/5th of the power needed by traditional x-ray systems to achieve high levels of detection sensitivity.

5 Year Generator Warranty

All x-ray generators have a 5-year warranty when a standard or comprehensive service contract is purchased.

Global Presence, Local Support

A global network of service engineers is on-hand to guide manufacturers on how to optimise the performance of the X34 and reduce the effects of unscheduled downtime through supporting clients locally.
