Raytec Vision – Al Thika Packaging LLC

Al Thika Packaging is the distributor of Raytec Vision. Since 1994 Al Thika Packaging has been supplying sorting machines for nuts, fruit and vegetable industries in Dubai, Abu Dhabi, Sharjah, Fujairah, Ras Al Khaimah, Ajman, Umm Al Quwain, Al Ain – UAE, Muscat, Oman and the many other Gulf countries.

Technology of Dryce Optical Sorter

• NIR technology can detect the presence of rotten and foreign bodies.
• Visible Color analysis allows colour defects to be detected, such as green products, yellowing, etc.
• The Chlorophyll analysis allows very accurate detection of foreign bodies in products with high chlorophyll content (peas, green beans).
• Translucency analysis enables detection of stones in the dehydrated fruit and contaminants with a different density from the good product.
• The Shape function calculates nine mathematical parameters for each inspected object. Those parameters are representative of geometric characteristics of the object such as eccentricity, compactness or the presence of protuberance.
• The Blob function rejects only the groups of pixels (blobs) whose sum of weights is higher than a value defined in the sorting recipe.
• The Stem function allows the detection and rejection of stalks, stems, wires or any other thin object in the product stream.
• The Glass function enables to detect and reject transparent pieces of glass and plastic.
• The Big Stop allows to control the presence of dangerous foreign bodies. This function enables a series of programmable choices: object calculation allocated in three different classes of dangerousness, automatic image capture of dangerous contaminants, alarm generation (with option to stop the machine).The machine detects statistical data on rejected products for quality analysis of the selected raw material.
• An ethernet connection is available for remote control. The Raymote safe connection is available for internet access. The Raymote Firewall allows to connect automatically to Raytec’s control systems, guaranteeing an efficient, continuous and safe assistance: Raymote has been designed to avoid external hacks.
