Ecoplat Plus
Turntable stretch wrapping machine
Ecoplat Plus is available in two versions, Basic and FRD. The Basic version is equipped with panel with electromechanical buttons, the FRD version has a panel LED display and a parameters selector by JOG.
| Max reel weight | 20kg |
| Max reel dimensions | 500x300mm |
| Film thickness | 17÷35 μm |
| Maximum product height | 2200mm std. 2400mm opt. |
| Forklifting | front and rear |
Industries: Logistics | Furniture | Paper | Agriculture | Bakery | Dry Food | Bulk Foods | Cosmetics | Confectionery | Dairy | Meat & Poultry | Chemical | Pet Food | Pharma |Ready Meals | Snack Foods | Seafood | Non-Food
- Description
- Technical Specs
- Brand
- Media
Description
Ecoplat Plus by Robopac
The Ecoplat Plus by Robopac is an efficient and reliable pallet stretch wrapping machine, designed to streamline packaging operations across diverse industries. With its user-friendly interface and versatile functionality, the Ecoplat Plus offers customisable wrapping programs to ensure optimal load stability. It is engineered for consistent performance, making it an ideal solution for improving operational productivity and protecting palletised goods during transit.
Produced by Robopac
AVAILABLE MODELS
Ecoplat Plus Base
Panel with electromechanical buttons.
The Control Panel on the Ecoplat Plus Base Pallet Wrapper allows you to easily set all the functions of the cycle through the use of electromechanical buttons.
ADJUSTABLE PARAMETERS / FEATURES
Top and bottom wraps
Upward-downward carriage speed
Turntable rotation speed
Emergency stop
IP54 – protection against water and dust
Ecoplat Plus FRD
Panel LED display and a parameters selector by JOG.
The Control Panel on the Ecoplat FRD Pallet Wrapper has Clear Icons to make it easy to programme and offers more functions and flexibility than the Ecoplat Base.
ADJUSTABLE PARAMETERS / FEATURES
Upward-downward cycle
Only downward or upward cycle
Top sheet cycle
Manual cycle
Eco cycle (recorded)
Top wraps / Bottom wraps
Reinforcement wraps
Turntable rotation speed
Upward-downward carriage speed
Photocell or altimeter
Carriage ergonomic stop
Emergency stop
IP54 – protection against dust and water
Robopac – Al Thika Packaging LLC
Al Thika Packaging is the exclusive distributor of Robopac in the Middle East. Since 1994 Al Thika has been supplying vertical pallet stretch wrappers and horizontal stretch wrapping machines for food, beverages & non-food industries in Dubai, Abu Dhabi, Sharjah, Fujairah, Ras Al Khaimah, Ajman, Umm Al Quwain, Al Ain – UAE, Muscat, Oman, Bahrain, Kuwait, Qatar and the many other Gulf countries.
FRD CARRIAGE
Technical features of Ecoplat Plus pallet wrapper
| Turntable diameter | mm | 1500 std. 1650 opt. |
| Max load weight | kg | 1200 std. 2000 opt. (BASE), 2000 (FRD) |
| Turntable speed | rpm | 4÷10 |
| Carriage up-down speed | m/min | 1,4÷4 |
| Maximum product dimensions (LxW) | mm | 800×1200 std. 1000×1200 opt. |
| Maximum product height | mm | 2200 std. 2400 opt. |
| Film carriage type | FRD | |
| Film stretch | manual (FRD) | |
| Film pre-stretch | n.a. | |
| Forklifting | front and rear | |
| Power supply voltage | V | 230 V 1Ph |
| Power supply frequency | Hz | 50/60 |
| Installed power | kW | 1,2 |
| Max reel dimensions | mm | 500×300 |
| Max reel weight | kg | 20 |
| Film thickness | μm | 17÷35 |
