Masterplat Plus
Turntable stretch wrapping machines
The Masterplats are the latest range of Turntable Pallet Wrappers from Robopac. Designed using the best features from the Ecoplats with the performance of the Rotoplats.
| Max reel weight | 20kg |
| Max reel dimensions | 500x300mm |
| Film thickness | 17÷35 μm |
| Max load weight | 2000 std. 2500 opt. (kg) |
| Forklifting | front and rear |
Industries: Logistics | Furniture | Paper | Agriculture | Bakery | Dry Food | Bulk Foods | Cosmetics | Confectionery | Dairy | Meat & Poultry | Chemical | Pet Food | Pharma |Ready Meals | Snack Foods | Seafood | Non-Food
- Description
- Technical Specs
- Brand
- Media
Description
Masterplat Plus Turntable Machine
Turntable stretch wrapping machines by Robopac
The Masterplat by Robopac is an advanced pallet stretch wrapping machine designed for enhanced operational efficiency and reliability. Featuring cutting-edge technology and customisable wrapping options, it ensures optimal load stability while catering to the diverse demands of industrial applications. Its robust design and user-friendly interface make the Masterplat a dependable solution for improving packaging workflows and protecting goods during transit.
Produced by Robopac
FRD CARRIAGE
Film carriage with mechanical brake manually adjustable to set the film tensioning. Brake engagement- release device to facilitate hooking the film to the base of the pallet.
PGS CARRIAGE
The PGS film delivery device is equipped with a powered fixed gear (250%) pre-stretch system. A wide range of additional gear sets can also be purchased (150%-200-300%).
3,5 Inches colour graphic display
Parameter selection by jog: programming of the cycles in a simple and intuitive way
AVAILABLE MODELS
Masterplat Plus Inox
Stainless steel wrapping turntable for use in the foodstuffs field, and outside place with high humidity.
BENEFITS:
- The perfect solution for companies working in the food industry
- Greater resistance to oxidation and corrosion
- Stainless steel material for environments with a high humidity level
- Possible version for temperatures up to -30°C
Masterplat Plus Freezer
Wrapping turntable freezer for use in the foodstuffs field and low temperature environments (-30°).
BENEFITS:
- Working temperature up to -30°C
- Ideal for food products
- Silicone cables suitable for low temperatures that ensure long life
Frequently Asked Questions About Masterplat Plus by Robopac
The Masterplat Plus is a semi-automatic turntable pallet wrapping machine used to wrap palletized loads with stretch film. It helps businesses in Dubai and the UAE improve load stability, protect goods during transport, and increase packaging efficiency.
The Masterplat Plus can handle pallet loads up to 2000 kg as standard and up to 2500 kg (optional), making it suitable for heavy-duty industrial applications.
The machine supports pallet sizes up to 1000 × 1200 mm (standard) and can wrap products up to 2200 mm height, with higher mast options available for taller loads.
The Masterplat Plus improves efficiency by automating the wrapping process, ensuring consistent film application, and reducing manual labor. It also supports pre-stretch film technology (up to 250%), helping reduce film consumption and packaging costs.
The Masterplat Plus is widely used in logistics, food and beverage, FMCG, manufacturing, and distribution centers where consistent pallet wrapping is required for medium to high production volumes.
The Masterplat Plus can wrap up to approximately 30 pallets per hour, depending on load size and wrapping settings, making it suitable for busy warehouse operations.
The Masterplat Plus pallet wrapping machine is available through trusted suppliers like Al Thika Packaging LLC, offering installation, training, and after-sales support across Dubai and the UAE.
Robopac – Al Thika Packaging LLC
Al Thika Packaging is the exclusive distributor of Robopac in the Middle East. Since 1994 Al Thika has been supplying vertical pallet stretch wrappers and horizontal stretch wrapping machines for food, beverages & non-food industries in Dubai, Abu Dhabi, Sharjah, Fujairah, Ras Al Khaimah, Ajman, Umm Al Quwain, Al Ain – UAE, Muscat, Oman, Bahrain, Kuwait, Qatar and the many other Gulf countries.
Technical features of Masterplat
| Turntable diameter | mm | 1650 std. 1800 opt. |
| Max load weight | kg | 2000 std. 2500 opt. |
| Turntable speed | rpm | 5÷12 |
| Carriage up-down speed | m/min | 1,4÷4 |
| Maximum product dimensions (LxW) | mm | 1000×1200 std. 1200×1200 opt. |
| Maximum product height | mm | 2200 std. 2400/2800/3100 opt. |
| Film carriage type | FRD, PGS | |
| Film stretch | manual (FRD), adjustable from panel (PGS) | |
| Film pre-stretch | n.a. (FRD), fixed 250% std. (PGS) | |
| Forklifting | front and rear | |
| Power supply voltage | V | 230 V 1Ph |
| Power supply frequency | Hz | 50/60 |
| Installed power | kW | 1,5 (FRD) / 1,9 (PGS) |
| Max reel dimensions | mm | 500×300 |
| Max reel weight | kg | 20 |
| Film thickness | μm | 17÷35 |
