Ecowrap Plus XL
Semi-automatic rotating arm stretch wrapping machine
Semi-automatic rotating arm stretch wrapping machine for unstable and heavy products.
| Arm rotation speed | (rpm) 7÷11 |
| Maximum product dimensions (LxW) | (mm) 1200×1200 |
| Maximum product height | (mm) 2000 |
| Film carriage type | FRD |
| Power supply voltage | 230 V 1 Ph |
Industries: Logistics | Furniture | Paper | Agriculture | Bakery | Dry Food | Bulk Foods | Cosmetics | Confectionery | Dairy | Meat & Poultry | Chemical | Pet Food | Pharma |Ready Meals | Snack Foods | Seafood | Non-Food
- Description
- Technical Specs
- Brand
- Media
Description
Ecowrap Plus XL Rotating Arm by Robopac
Semi-automatic rotating arm stretch wrapping machine
Semi-automatic rotating arm stretch wrapping machine for unstable and heavy products.
Produced by Robopac
FRD CARRIAGE
Film carriage with mechanical brake manually adjustable to set the film tensioning. Brake engagement- release device to facilitate hooking the film to the base of the pallet.
CONTROL PANEL
Panel LED display and a parameters selector by JOG.
OPTION
R-Connect
Innovation and connection for customer service: the tranquillity of maximum productivity as a result of constant monitoring of proper machine operation.
Powerful, plug & play and user friendly, R-Connect is a “turnkey” system for the end-user: the main advantage is total “peace of mind”, which is absolute tranquillity regarding machine operation, which includes production performance verification and optimisation of all management costs.
In fact, the system minimises machine downtime and manages maintenance operations better, also providing an immediate troubleshooting procedure, until the full and remote upgrade of the machine’s management software is completed.
Pallet lifting frame
Metal structure that keeps the load raised from the ground useful for the complete wrapping of the pallet.
It is a rotating arm wrapping machine. Because the pallet does not move, it is specifically designed to stabilize “difficult” loads—such as very light products that would fall over if spun, or extremely heavy industrial equipment that would crush a standard turntable.
Frequently Asked Questions About the Ecowrap Plus XL
It provides versatility and floor safety. Since the pallet sits directly on the warehouse floor, you don’t need a ramp or a forklift to lift it onto a base. It also allows you to wrap “unlimited” weight loads, as the machine doesn’t have to support the pallet’s mass.
Width & Length: Up to 1200 x 1200 mm as standard.
Height: The standard wrapping height is 2000 mm.
Weight: Unlimited. Since the load stays on the ground, the only weight limit is what your warehouse floor can support.
The arm rotation speed is adjustable from 7 to 11 RPM. This allows you to wrap up to 25–30 pallets per hour.
ToIt uses the FRD Carriage.
The Ecowrap Plus XL is available through authorised suppliers such as Al Thika Packaging LLC, offering complete solutions, including installation, technical support, and after-sales service, across Dubai and the GCC.
Robopac – Al Thika Packaging LLC
Al Thika Packaging is the exclusive distributor of Robopac in the Middle East. Since 1994 Al Thika has been supplying vertical pallet stretch wrappers and horizontal stretch wrapping machines for food, beverages & non-food industries in Dubai, Abu Dhabi, Sharjah, Fujairah, Ras Al Khaimah, Ajman, Umm Al Quwain, Al Ain – UAE, Muscat, Oman, Bahrain, Kuwait, Qatar and the many other Gulf countries.
Technical features of Ecowrap Plus XL
| Arm rotation speed | rpm | 7÷11 |
| Carriage up-down speed | m/min | 2,6÷6 |
| Maximum product dimensions (LxW) | mm | 1200×1200 |
| Maximum product height | mm | 2000 |
| Film carriage type | FRD | |
| Film stretch | manual | |
| Film pre-stretch | n.a. | |
| Power supply voltage | V | 230 V 1 Ph |
| Power supply frequency | Hz | 50/60 |
| Max reel dimensions | mm | 500×275 |
| Max reel weight | kg | 8 |
| Film thickness | μm | 7÷35 |
