Robot S7 Stop & Go
Self propelled robot for pallet stretch wrapping
Robopac introduces Robot S7 Stop & Go, a new generation of self-propelled packaging machines, developed with the company’s established expertise. Characterised by high autonomy and flexibility, it is distinguished by its ability to stop instantly through the laser scanner in the presence of obstacles, automatically resuming operation once the obstacle is removed, thus ensuring operator safety without any direct contact.
| Power Drive | Power Drive, perfect film control with brushless motors and new performing carriages |
| ILS | Instant Load System, easy and immediate film insertion |
| Battery | Lithium Battery |
| E-Saving | E-Saving, the lowest energy consumption on the market |
| Technology | Touch screen control panel with Cube Technology |
| Stop & Go | Contact prevention and automatic restart |
Industries: Logistics | Furniture | Paper | Agriculture | Bakery | Dry Food | Bulk Foods | Cosmetics | Confectionery | Dairy | Meat & Poultry | Chemical | Pet Food | Pharma |Ready Meals | Snack Foods | Seafood | Non-Food
- Description
- Technical Specs
- Brand
- Media
Description
Robopac Robot S7 Stop & Go Pallet Wrapper
Self propelled robot for pallet stretch wrapping with patented automatic stop and restart system
Robopac introduces Robot S7 Stop&Go, a new generation of self-propelled packaging machines, developed with the company’s established expertise. Using advanced technology and prioritising safety, this machine is designed to wrap and stabilise palletised loads of various sizes and weights with stretch film. Characterised by high autonomy and flexibility, it is distinguished by its ability to stop instantly through the laser scanner in the presence of obstacles, automatically resuming operation once the obstacle is removed, thus ensuring operator safety without any direct contact.
Produced by Robopac
P3GS CARRIAGE
The P3GS pre-stretch carriage has a motorized pre-stretch with 3 selectable fixed ratios (0% -230% -300% std and 0% -150% -250% opt.)
PVS CARRIAGE
Carriage with powered stretch system controlled by two independent motors. Stretch ratio adjustable from panel board from 0% up to 500% .
CONTROL PANEL
The control panel with color touch screen allows you to create up to 12 programs (+12 with Cube Technology) in a simple and intuitive way thanks to the patented Robopac icons.
Robopac – Al Thika Packaging LLC
Al Thika Packaging is the exclusive distributor of Robopac in the Middle East. Since 1994 Al Thika has been supplying vertical pallet stretch wrappers and horizontal stretch wrapping machines for food, beverages & non-food industries in Dubai, Abu Dhabi, Sharjah, Fujairah, Ras Al Khaimah, Ajman, Umm Al Quwain, Al Ain – UAE, Muscat, Oman, Bahrain, Kuwait, Qatar and the many other Gulf countries.
Technical features of Robot S7 Stop & Go
| ROBOT S7 STOP&GO P3GS | ROBOT S7 STOP&GO PVS | ||
| n° of pallets per battery charge | >300 (Pb/Acid) | >300 (Pb/Acid) | |
| batteries | N°2 12 V 110 Ah Pb/Acid (std.) N°1 24 V 50 Ah Lithium (opt.) |
N°2 12 V 110 Ah Pb/Acid (std.) N°1 24 V 50 Ah Lithium (opt.) |
|
| maximum product height | mm | 2200 std. 2400/2800/3100 opt. |
2200 std. 2400/2800/3100 opt. |
| minimum dimensions (LxW) | mm | 600×600 | 600×600 |
| film carriage type | P3GS | PVS | |
| film stretch | adjustable from panel | adjustable from panel | |
| film pre-stretch | 0% – 230 % – 300 % (std.) 0% – 150% – 250% (opt.) |
variable 0-500% | |
| power supply voltage | V | 100-240 V (1Ph) 50/60Hz | 100-240 V (1Ph) 50/60Hz |
| machine rotation speed | m/min | 35÷80 | 35÷80 |
| carriage up-down speed | m/min | 1,5 ÷ 5 | 1,5 ÷ 5 |
| maximum reel dimensions (HxØ) | mm | 500×300 | 500×300 |
| maximum reel weight | kg | 20 | 20 |
| film thickness | μm | 7÷35 | 7÷35 |
